AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components

Product Categories
Anterwell Technology Ltd.
Contact Now

AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components

Brand Name : ATMEL

Model Number : AT29C256-70PC

Certification : Original

Place of Origin : Original

MOQ : 5 PCS

Price : 0.1USD

Payment Terms : T/T, Western Union,Paypal

Supply Ability : 10000PCS/DAY

Delivery Time : 1 day

Packaging Details : contact us for more details

Voltage : 5V

Features : Fast Read Access Time – 70 ns

Description : in-system Flash programmable

Temperature : /

Use : /

Type : IC CHIP

Contact Now

AT29C256-70PC IC 256K 32K x 8 5-volt Only CMOS Flash Memory
Features
Fast Read Access Time – 70 ns
5-volt Only Reprogramming
Page Program Operation
– Single Cycle Reprogram (Erase and Program)
– Internal Address and Data Latches for 64 Bytes
Internal Program Control and Timer
Hardware and Software Data Protection
Fast Program Cycle Times
– Page (64 Byte) Program Time – 10 ms
– Chip Erase Time – 10 ms
DATA Polling for End of Program Detection
Low-power Dissipation
– 50 mA Active Current
– 300 µA CMOS Standby Current
Typical Endurance > 10,000 Cycles
Single 5V
±10% Supply
CMOS and TTL Compatible Inputs and Outputs
Commercial and Industrial Temperature Ranges
256K (32K x 8)
5-volt Only
Flash Memory
AT29C256
Description
The AT29C256 is a five-volt-only in-system Flash programmable and erasable read only memory (PEROM). Its 256K of memory is organized as 32,768 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the device offers access times to 70 ns with power dissipation of just 275 mW. When the device is deselected, the CMOS standby current is less than 300 µA. The device endurance is such that any sector can typically be written to in excess of 10,000 times.
Pin Name
Function
A0 - A14 Addresses
CE Chip Enable
OE Output Enable
WE Write Enable
I/O0 - I/O7 Data Inputs/Outputs
NC No Connect
DC Don’t Connect

AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components
AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components
